Fixed Speeds
1500 r/min
1800 r/min
Engine Prime Power
300 kw
Jupiter Series
LP4B27NG1, LP4E36NG1, LP4E51NG1, LP6E77NG1, LP6E128NG1, LP6E145NG1, LP6E156NG1, LP6E252NG1
| Engine prime power (kW) @1500rpm | 300 |
|---|---|
| Engine prime power (kW) @1800rpm | 300 |
| Typical genset prime power (kW) @1500rpm | 250 |
| Typical genset prime power (kW) @1800rpm | 250 |
| Type | 4-stroke-cycle, in-line, 6 cylinders |
| Bore / Stroke (mm) | 130/161 |
| Displacement (L) | 12.8 |
| Aspiration | Turbocharged intercooled |
| Flywheel housing | SAE1 |
| Flywheel diameter | 14″ |
| Number of flywheel teeth | 143 |
| Mechanical efficiency (%) | 38.7 丨 38.5 丨 38.3 |
| Thermal efficiency (%) | 48.5 丨 48.5 丨 48 |
| Total efficiency (%) | 87.2 丨 87 丨 86.3 |
| Gaseous fuel type | Natural gas |
| Minimum fuel supply pressure (kPa) | 20 |
| Maximum fuel supply pressure (kPa) | 100 |
| Load (%) | 100 丨 75 丨 50 |
| Engine power (kW) | 300 丨 225 丨 150 |
| Gas consumption (m³/h) | 84.5 丨 63.7 丨 42.7 |
| Net weight (kg) | 1065 |
| Length X Width X Height (mm) | 2408 X 1130 X 1557 |
| Engine Series | Jupiter |
|---|---|
| Fuel Type | Gas |
| Power Range | 201-500 kW |
