Venus LP443G5

For 150 years, Lister Petter has led the field in design and manufacturing of high-performance diesel engines
Venus LP443G5

Venus LP443G5

Fixed Speeds
1500 | 1800 r/min

Maximum Power
1500 r/min—105-116kW
1800 r/min—120-132kW

Injection
Direct

Description

Venus

Models: LP443G1, LP443G2, LP443G3, LP443G4, LP443G5, LP443G6, LP665G1, LP665G2, LP665G3, LP689G1, LP689G2, LP689G3, LP612G1, LP612G2, LP613G1, LP613G2

One of Lister Petter’s leading engines, the Venus series comes with a mechanical or electronic governor option.
Tried and trusted technology offers easy maintenance and in-field servicing, while its compact design allows cost-effective gen-set packaging.

  • Dual frequency operation at 50 Hz / 60 Hz
  • High performance cooling system operates in ambient temperatures of up to 50 °C
  • Cold starts down to minus 40 °C
  • No altitude derating up to 3,500 m
  • Easy, cost-effective servicing with full global backup in parts and expertise from Lister Petter service outlets
  • Mechanical and electronic governor variants
  • 500-hour service intervals (depending on operating conditions)

Technical Specifications

Cooling System Liquid
Minimum Full Load Speed 1500 rpm
Maximum Full Load Speed 1800 rpm
Number of Cylinders 4 cylinders
Bore 105 mm
Stroke 124 mm
Displacement 4.3 L
Governor Electronic Governor
Injection Direct
Aspiration Turbo & Air to Air Intercooler
Starting Electric
Firing Order 1-3-4-2
Compression Ratio 16:1
Max Operating Temp 52 °C (122 ℉)
Weight 504 kg
Length 1,364 mm
Width 790 mm
Height 1,079 mm

Additional information

Emissions

Stage II

Engine Series

Venus

Fuel Type

Gas

Power Range

86-200 kW
