Fixed Speeds
1500 | 1800 r/min
Maximum Power
1500 r/min—49-54kW
1800 r/min—50-60kW
Injection
BOSCH Common Rail with ECU
LP311EVG1, LP322EVG1, LP322EVG2, LP430EVG2, LP311EG1, LP429EG1, LP432EG2, LP435EG2
The MERCURY MAX series, with ratings from 11 kW to 62 kW available in 1500 rpm and 1800 rpm. This is the first of the Stage V compliant engines in the range for Lister Petter. The engine uses a Bosch common rail fuel injection system and ECU to control fuel delivery and to achieve Stage V emissions compliance. The 3-cylinder 1.1 litre engine offers exceptional power in a compact package.
| Cooling System | Liquid |
|---|---|
| Minimum Full Load Speed | 1500 r/min |
| Maximum Full Load Speed | 1800 r/min |
| Number of Cylinders | 4L |
| Bore | 94 mm |
| Stroke | 107 mm |
| Displacement | 3.0 litres |
| Injection | BOSCH Common Rail with ECU |
| Aspiration | Turbo |
| Starting | Electric |
| Firing Order | 1-3-4-2 |
| Compression Ratio | 17.5:1 |
| Max Operating Temp | 52℃ (122℉) |
| Weight | 302 kg |
| Length | 1155 mm |
| Width | 670 mm |
| Height | 845 mm |
| Emissions | Stage V |
|---|---|
| Engine Series | Mercury Max |
| Fuel Type | Gas |
| Power Range | 0-85 kW |
