Mercury Max LP322EVG2

For 150 years, Lister Petter has led the field in design and manufacturing of high-performance diesel engines
Mercury Max LP322EVG2

Mercury Max LP322EVG2

Fixed Speeds
1500 | 1800 r/min

Maximum Power
1500 r/min—40-44kW
1800 r/min—49-54kW

Injection
BOSCH Common Rail with ECU

Description

LP311EVG1, LP322EVG1, LP322EVG2, LP430EVG2, LP311EG1, LP429EG1, LP432EG2, LP435EG2

The MERCURY MAX series, with ratings from 11 kW to 62kW available in 1500rpm and 1800rpm. This is the first of the Stage V compliant engines in the range for Lister Petter. The engine uses a Bosch common rail fuel injection equipment and ECU to control fuel delivery and to achieve Stage V emissions compliance. The 3-cylinder 1.1 litre engine offers exceptional power in a compact package.

  • Vertical injection, common rail fuel system
  • High-temp capability radiator for use in ambient temperatures up to 50ºC
  • Compact design with standard SAE connection
  • Cost effective: low cost, fuel efficient, low maintenance with full global spares back up from Lister Petter service outlets worldwide
Cooling System Liquid
Minimum Full Load Speed 1500 r/min
Maximum Full Load Speed 1800 r/min
Number of Cylinders 3L
Bore 94 mm
Stroke 107 mm
Displacement 2.2 litres
Injection BOSCH Common Rail with ECU
Aspiration Turbo & Intercooler
Starting Electric
Firing Order 1-3-2
Compression Ratio 17.5:1
Max Operating Temp 52℃(122℉)
Weight 180 kg
Length 790 mm
Width 560 mm
Height 720 mm

Additional information

Emissions

Stage V

Engine Series

Mercury Max

Fuel Type

Gas

Power Range

0-85 kW
