Fixed Speeds
1500 r/min
1800 r/min
Engine Prime Power
50 kW
Jupiter Series
LP4B27NG1, LP4E36NG1, LP4E51NG1, LP6E77NG1, LP6E128NG1, LP6E145NG1, LP6E156NG1, LP6E252NG1
| Engine prime power (kW) @1500rpm | 28 |
|---|---|
| Engine prime power (kW) @1800rpm | 28 |
| Typical genset prime power (kW) @1500rpm | 22 |
| Typical genset prime power (kW) @1800rpm | 22 |
| Type | 4-stroke-cycle, in-line, 4 cylinders |
| Bore / Stroke (mm) | 90 / 105 |
| Displacement (L) | 2.7 |
| Aspiration | Naturally Aspirated |
| Flywheel housing | SAE4 |
| Flywheel diameter | 7.5″ |
| Number of flywheel teeth | 115 |
| Mechanical efficiency (%) | 37.5 丨 37.3 丨 37 |
| Thermal efficiency (%) | 48.5 丨 48.5 丨 48 |
| Total efficiency (%) | 86 丨 85.8 丨 85 |
| Gaseous fuel type | Natural gas |
| Minimum fuel supply pressure (kPa) | 20 |
| Maximum fuel supply pressure (kPa) | 100 |
| Load (%) | 100 丨 75 丨 50 |
| Engine power (kW) | 28 丨 21 丨 14 |
| Gas consumption (m³/h) | 8.1 丨 6.1 丨 4.1 |
| Net weight (kg) | 280 |
| Length X Width X Height (mm) | 1115x695x880 |
| Engine Series | Jupiter |
|---|---|
| Fuel Type | Gas |
| Power Range | 50kW |
